3 Way 2 position Palm Button Latching Valve

From $66.00

In Stock
Make an Enquiry

The PBL32 series are a three way two position palm button latching, also known as an emergency stop valve. The button when pressed will stay down and can only be reset by rotating in the direction of the arrow. Simple to use, install and maintain.

3 way 2 position palm button spring valve

Specification PBL32-01 PBL32-02
Port Size G1/8” G1/4”
Button Colour Red Red
Pressure Range 0 to 10 BAR (147 psi)
Max Inlet Pressure 10 BAR (147 psi)
Medium Temperature -5 to 60°C
Body Die Cast Aluminium
End Caps Reinforced Plastic
Button Thermoplastic
Lubrication Not Required
Applicable Medium Air

1/8" 3 way 2 position palm latching valve1/4" 3 way 2 position palm latching valve

Size 1/8" to 1/4" BSP
Function 3 way 2 position palm button latching
Body Aluminium
Pressure Range 0 to 10 BAR
Media Air
