Features:
Size 3/4" to 1-1/2" BSP
Body 316 Stainless Steel
Pressure Range 0 to 7 BAR
Media Steam
The MS-6 Series of Noiselss heaters from Yoshitake are an all Stainless Steel unit with simple construction and trouble free operation. This heater uses a Lotus Root shape to draw the water in around the heater and through the side. It then mixes with the steam flow to create and inject heated water into the tank. These Noiseless heaters are quieter and more efficient at heating the water when compared to traditional sparge pipes. This is because the traditional sparge pipes typically produce inconsistent mixing of the steam and water as the steam is jetted directly into the tank, wasting steam and energy. Installation is quick and easy with the BSP threaded end connections
Application | Steam |
---|---|
Type | Noiseless Heater / Vacuum Relief |
Max Pressure | 7 Bar |
Connection | BSPT (ISO7.1 Rc) |
Body | Stainless Steel |
Capacity Chart for Noiseless Heater
Size | L (mm) | D (mm) | Weight (kg) |
---|---|---|---|
1/2" BSPT | 48.5 | 35 | 0.25 |
3/4" BSPT | 49 | 45 | 0.4 |
1" BSPT | 52 | 50 | 0.52 |
1 1/4" BSPT | 55 | 60 | 0.77 |
1 1/2" BSPT | 59 | 70 | 1.15 |
2" BSPT | 65 | 105 | 2.99 |
